117
For details about SL key restrictions, see “SL Key
Restrictions” (page 466).
To use the SL key function, the
following options are
required.
• XKS-G1600 GPU Pack
• XZS-G1620 SL Key License
When the system signal format is 21
60P, the SL key
function must be enabled for use.
For details about setting GPU functions, see “Setting a
GPU” (page 364).
Key fill/key source for SL keys
Still image combined content is used as the key fill/key
source for SL keys.
When content is selected as a key fil
l/key source for an SL
key, the content must be loaded into the SL key work area
using the key 5 to key 8 menus.
The number of content resources that
can be loaded into
an SL key is given below.
Key Type
The key type sets the manner in which the key source is
used to cut out the background.
For details about key types, see “Key Type” (page 115).
Setting the Key Type (Menu)
This section describes the M/E-1 key 1 menu as an
example.
Setting the key type
1
Open the Home > M/E-1 > Key1 > Type > Type
Select menu (11101.11).
2
In the [Key Type] group, select a key type.
Luminance: Lumi
nance key
Linear: Li
near key
Chroma: Chroma
key
Key Wipe Pattern:
Key wipe pattern key
When the [Luminance] button or [Li
near] button is
selected, set the following parameters.
a) No filter is applied when set to “1”. The larger the value, the
stronger the filtering applied.
When the [Chroma] button is selected, set the
following parameter.
When the [Key Wipe Pattern] button
is selected, set
the following parameters.
System signal format Number of content
resources
2160P 20
1080P 80
1080i 80
720P 180
No. Parameter Adjustment
1 Clip Reference level for key signal
ge
neration
2 Gain Key gain
3 Density Key density
4 Filter Filter (1 to 9)
a)
No. Parameter Adjustment
3 Density Key density
No. Parameter Adjustment
1 Size Pattern size
2 Soft Softness of the pattern
contou
r
3 Density Key density
To Next Page
