245
The enable/disable setting is applied to all link groups.
1
Open the Home > Other Effects > Aux Bus > Aux
Bus CCR menu (18102.21).
2
Set the [Link Enable] button in the [Aux Bus CCR
Link] group to the on state.
To disable a link group, set
the [Link Enable] button
to the off state.
To apply the same settings to color correctors in
a group
If the settings of AUX bus color correc
tors within a group
are different, you can set the same settings by copying the
settings of a specific AUX bus.
Select an AUX bus and press the [Copy in Link Group]
bu
tton in the [Aux Bus CCR Link] group.
The color corrector of all AUX bu
ses in the group are set
to the same settings as the selected AUX bus.
Color Backgrounds
Overview
A color background is a function used to create a color
background image using a color signal generated by a
dedicated generator.
When the system signal format is 2160P, one color
backg
round (color background 1) can be used. When the
system signal format is 1080P, 1080i, or 720P, two color
backgrounds (color background 1 and color background
2) can be used.
Assign color background 1 and color background 2 to
cross-
point buttons, and select color background signals.
Types of color backgrounds
You can set a single color (color 1 only) or a color mix
(mix o
f color 1 and color 2) color background.
In a color mix, color 1 and color 2 are mixed using a
dedi
cated pattern. You can also add modifiers to the
pattern.
Setting a Color Background
This section describes the color background 1 menu as an
example.
Setting a single color background
1
Open the Home > Other Effects > Color Bkgd >
Color Bkgd1 menu (18101.11).
2
Set the [Flat Color] button in the [Matte] group to the
on state and set the following parameters.
Setting a color mix color background
1
Open the Home > Other Effects > Color Bkgd >
Color Bkgd1 menu (18101.11).
2
Set the [Mix Color] button in the [Matte] group to the
on state and set the following parameters.
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Size Pattern size
