Chapter
442
System Configuration
and Management
System Configuration menu
This menu is used to configure network settings and the
components of the switcher system, and to create user
accounts.
Administrator privileges are re
quired for some menu
operations.
For details about system configuration, refer to the
XV
S-G1 Installation Manual.
Configuring System
Devices
Detecting devices connected to the
network
You can detect control panels connected to the network of
the switcher system.
On the ICP-X7000, information
is detected for each
control panel row. The name of the module located on the
right side of each row is displayed in [Device Type]. If
there is no module located in a control panel row,
“MKS-7099” (CPU module name) is displayed.
1
Open the System Configuration > Configuration >
System menu (20101.11).
2
Press the [Detect/Refresh] button.
The information and status of the detected control
p
anels are displayed.
“ ” is displayed for connected control panels/
connected control panel rows.
Configuring devices connected to the
network
Select a control panel or control panel row to use and
configure the network information.
• Switcher settings cannot be changed.
The host name of the switche
r is set in the System
Configuration > Network > Network Settings menu
(20201.11).
• On the ICP-X7000, set the infor
mation for each control
panel row. Up to 14 rows can be configured for a single
control panel.
On the ICP-X1000 series, set
the information for each
control panel.
Note
Notes
