Setting the Signal Format
Setting the Signal Format and
Frequency
You can select the system signal format and the field
frequency/frame frequency.
The combinations of signal forma
t and frequency that can
be set are as follows.
To use 4K formats, the XZS-G1500 4K Upgrade License
(option) i
s required.
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
2 In the [Signal Format] group, select a signal format.
3 In the [Frequency] group, select a frequency.
4 Press the [Apply] button in the [Signal Format/
Frequency/Ref] group.
To return to the previous setting
Press the [Clear] button in the [Signal Format/
Frequ
ency/Ref] group.
5 Check the message, then press [OK].
The switcher system reboots.
Setting the Reference Signal
You can set the input/output reference signal to HD tri-
level sync or black burst.
When the system signal format is 720P and the frequency
is 50,
the reference signal is set to black burst (fixed).
Setting the reference signal lock mode
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
2 In the [Ref Lock Mode] group, select a lock mode.
External: Exte
rnal lock mode
Sync to input reference signal
.
Internal: Internal lock mode
Use switcher internal signal as the reference
signal.
3 Press the [Apply] button in the [Signal Format/
Frequency/Ref] group.
To return to the previous setting
Press the [Clear] button in the [Signal
Format/
Frequency/Ref] group.
4 Check the message, then press [OK].
The switcher system reboots.
Setting the input reference signal
Cannot be set when the reference signal is in internal lock
mode.
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
2 In the [Ref Input Format] group, select a reference
signal.
Tri Sync: HD
tri-level sync
BB: Black bu
rst or sync
3 Press the [Apply] button in the [Signal Format/
Frequency/Ref] group.
To return to the previous setting
Press the [Clear] button in the [Signal
Format/
Frequency/Ref] group.
4 Check the message, then press [OK].
The switcher system reboots.
Setting the output reference signal
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
Signal format Frequency
4K 2160P 2SI 59.94
50
HD 1080P 59.94
50
1080i 59.94
50
720P 59.94
50
Note
Note
Note
