183
Still Image Operations
This section describes the operation on frame memory
output channel 1 (FM1) as an example.
Creating a Still Image (Freeze)
You can assign a frame memory source bus signal to a
frame memory output channel and then execute a freeze
to capture still image content and save it in frame
memory.
When the system is powered off, the content in frame
me
mory will be lost. Save any required content in content
storage.
For details, see “Saving content to content storage”
(page 182).
1
Open the Home > Frame Memory > FM1/FM2 >
Clip/Still > Record menu (13101.13).
To enable group mode
Set the [Group Mode] button to the on state.
When group mode is enabled, the frame memory
ou
tput channel display changes to [FM1/FM2].
2
Set the [Through] button for [FM1] to the on state.
The frame memory source bus signal is output on the
frame m
emory output channel.
The output signal of the frame memory output
ch
annel is delayed by one frame.
3
Press the [Freeze] button for [FM1].
The still image content is saved
in the folder specified
in the properties for frame memory source 1.
To enable V/K mode
Set the [V/K Mode] button to the on state.
Recalling a Still Image
1
Open the Home > Frame Memory > FM1/FM2 >
Clip/Still > Recall menu (13101.11).
Content can be displayed in list view or thumbnail
view
.
The frame memory output channels are shown on the
left.
To enable group mode
Set the [Group Mode] button to the on state.
When group mode is enabled, the frame memory
ou
tput channel display changes to [FM1/FM2].
2
Select [FM1].
3
Select content to recall.
The selected content is recalled and displayed on the
frame memory output
channel.
When group mode is disabled for frame memory
output cha
nnels and combined content is selected,
only content 1 of the combined content is recalled on
frame memory output channel 1.
Note
Note
Note
