Control Panel Setup
Setting the Control Panel
Configuration
Assigning a Switcher Bank/AUX
Setting M/E banks and AUX banks
(ICP-X7000)
You can select control panel rows (up to six) for use as
M/E banks and assign switcher banks (M/E-1 to M/E-5,
P/
P). You can also select control panel rows (up to two)
for use as AUX banks and assign AUX (AUX 1 or AUX
2).
The bank numbers correspond to the line ID (1 to 14)
co
nfigured for the control panel rows.
For details about setting the line ID, see “Configuring
devices connected to the network” (page 442).
Only the control panel rows to
which an MKS-X7017/
X7018/X7019 cross-point module is connected can be
configured.
The MKS-X7017/X7018/X7019 functions as a cross-
po
int control block when the control panel row is
configured as an M/E bank or functions as an AUX bus
control block when configured as an AUX bank.
1
Open the Home > Setup > Panel > Config > M/E /
AUX Assign menu (19104.11).
2
Select the target M/E / AUX bank number to set.
3
Press the [Assign] button and select a switcher bank
(M/E-1 to M/E-5, P/P) or AUX (AUX 1, AUX 2)
from the pull-down list.
To assign no switcher bank or AUX, select [- - -].
Setting M/E banks (ICP-X1000 series)
You can select the switcher bank to assign to an M/E
bank.
The M/E bank number indicates a ph
ysical position on the
control panel. On a control panel with two M/E bank
rows, the rows are numbered 1 and 2 from the back.
1
Open the Home > Setup > Panel > Config > M/E /
AUX Assign menu (19104.11).
2
Select the target M/E bank number to set.
3
Press the [Assign] button and select a switcher bank
(M/E-1 to M/E-5, P/P) from the pull-down list.
To assign no switcher bank, select [- - -]
.
Setting Switcher Banks in Multi
Program 2 Mode
In multi program 2 mode, you can set main/sub for each
switcher bank assigned to an M/E bank.
You can select dedicated main,
dedicated sub, or shared
main and sub.
1
Open the Home > Setup > Panel > Config > M/E /
AUX Assign menu (19104.11).
2
Select the target switcher bank to set.
3
Press the [Main/Sub] button and select main/sub from
the pull-down list.
Main: Dedi
cated main
Sub: De
dicated sub
Main&Sub: Shared
main and sub
When dual M/E is enabled, you can set main and sub
to
the shifted state and unshifted state of a switcher
bank assigned to two M/E banks.
The shifted/unshifted settings for dual M/E are
cle
ared.
Note
Note
To Next Page
