Power Supply and Connectors
XVS-G1 Multi Format Switcher
Front view
a Power button
Turns the switcher on/off.
The button is lit when turned on.
b Front panel LED
Displays the status of the switcher by the color and flash
rate of the
LED.
Normal operation: Lit blue
While starting/shutting down: Flashing
When an error occurs: Lit red
When a warning occurs: Lit yellow
c Display
Displays the switcher model a
nd other information.
You can switch the display items using the [SELECT]
bu
tton.
For details, see “Display items and operations”
(page 57).
d SET bu
tton
Used when executing items sh
own on the display.
e SELECT but
ton
Selects the display items shown on the display.
The next item is shown each time the [SELECT] button is
presse
d.
f Status indicators
Displays the status by the c
olor of the LEDs. Lit green
during normal operation.
REF indicator: Reference status
Lit red when an error occurs.
FAN indicator: Fan status
Lit red when an error occurs and
lit amber when a
warning occurs.
COM indicator: Switcher status (excluding reference,
f
an, and network)
Lit red when an error occurs and
lit amber when a
warning occurs.
NETWORK indicator: Network status
Lit red when an error occurs and
lit amber when a
warning occurs.
Display items and operations
The following six items are displayed in sequence each
time the
[SELECT] button is pressed.
• Model name of the switcher (XVS-G1)
• Host name of the switcher
• IP/Mac Address:
Displays the IPv4 address an
d MAC address of the
network interface.
• Device Info:
Displays the serial number and version of the switcher.
• Initialize:
Initializes the IP address and system setup.
Pressing the [SET] button displays an execution
co
nfirmation message. Press the [SET] button to
execute initialization.
To cancel execution, press the [SEL
ECT] button.
• Password Reset:
Resets the password of the administrator user account.
To Next Page
