281
Temporary attributes
Apart from attributes set in a snapshot register, you can
add temporary attributes when a snapshot is recalled. You
set temporary attributes when recalling a snapshot.
Bus Override
This function is used to recall a snapshot while
maintaining the cross-point selection of background A
bus or B bus.
When you press and hold a background A bus or B bus
cross-point button
and recall a snapshot, the cross-point
selection state is maintained for the pressed button only.
This is useful for temporarily holding a cross-point
sele
ction when cross-point hold is not set.
Snapshot Operations
(Flexi Pad Control Block)
In the Flexi Pad control block, you can perform
operations on snapshots for switcher bank region targets.
You can save and recall a snapshot using the Flexi Pad
con
trol block of the target switcher bank.
Memory recall section in snapshot
operation mode
Pressing the [SNAPSHOT] button in the Flexi Pad
control block switches the memory recall section to
snapshot operation mode.
You select registers (1 to 99) and
set attributes using the
buttons in the memory recall section.
To allow operations on the 99 snapshot registers, the
Flex
i Pad control block groups the registers. A register
group is called a bank.
There are ten banks (0 to 9) and you display and select the
b
ank corresponding to the target register.
Ten registers are displayed in each bank. Bank 0 displays
register
numbers 1 to 9, bank 1 displays register numbers
10 to 19, and so on.
The currently selected bank number and re
gister number
are displayed on the top right button in the memory recall
section.
A register number is not assigned to the bottom left button
o
f bank 0. You can assign any register number.
For details, see “Assigning a register to bottom left
button of bank 0” (page 414).
Selecting a bank
You can switch banks using the following buttons.
To select bank 0: Press the [BANK0] button.
To select bank 1: Press the [BANK1] button.
To select bank 2: Press the [BANK2] button.
To select bank 0 to 9: Press the [BANK SEL] button and
ent
er a bank number (0 to 9) using the numeric
keypad in the memory recall section.
To select the previous bank, press the [PREV BANK]
button in the
memory recall section.
To select the next bank, press the [NEXT BANK] button
in
the memory recall section.
Selecting a register
The selected bank register is displ
ayed in the memory
recall section. Press the button for the target register to
select it.
The register name or register number is displayed on
buttons for registers
with a registered snapshot.
Note
To Next Page
