158
2
Set the [Spiral] button to the on state and set the
following parameters.
Setting an Independent
Key Transition Wipe
Wipe patterns and modifiers for independent key
transitions are configured using the menu.
This section describes the M/E-1 key 1 menu as an
example.
Setting a Wipe Pattern for an
Independent Key Transition
Selecting a wipe pattern
Only standard wipe patterns can be used in an
independent key transition.
1
Open the Home > M/E-1 > Key1 > Transition > Wipe
menu (11101.52).
2
Press the [Pattern Select] button.
A pattern selection window appears.
3
Set the button for the target wipe pattern to the on
state.
4
Press [OK].
Setting Independent Key Transition
Wipe Modifiers
You can set the following modifiers in an independent
key transition.
• Direction
•Soft edge
• Position
•Rotation
•Aspect
• Multiplication
Setting the wipe direction (Direction)
1
Open the Home > M/E-1 > Key1 > Transition > Wipe
menu (11101.52).
2
In the [Direction] group, select a wipe direction.
Normal: Wipe in
normal direction.
No. Parameter Adjustment
1 Magnitude Size and direction of the
spiral
• A value of –100.00
repre
sents the maximum
movement in the
counterclockwise direction.
• A value of +100.00
repre
sents the maximum
movement in the clockwise
direction.
2 Wave Speed Speed of the lateral waves
• Negative values set the
spee
d from the left.
• Positive values set the
speed from the right.
Note
To Next Page
