Sony XVS-G1 User Manual

171
Setting an Independent
Key Transition DME Wipe
DME wipe patterns and modifiers for independent key
transitions are configured using the menu.
This section describes the M/E-1 key 1 menu as an
exampl
e.
Setting a DME Wipe Pattern for an
Independent Key Transition
In an independent key transition, wipe pattern parameters
cannot be adjusted.
Selecting a DME wipe pattern
1 Open the DME wipe pattern selection menu.
In 1-channel mode, open the Home > M/E-1 > Key1
> Transitio
n > 1ch Pattern menu (11101.54).
In 2-channel mode, open the Home > M/E-1 > Key1
> Transitio
n > 2ch Pattern menu (11101.55).
2 Press the button for a DME wipe pattern group.
The patterns in the selected gr
oup are displayed.
For 1-channel mode
Select from the following DME wipe pattern groups.
Slide / Squeeze: Slide
and squeeze
Split / Door: Sp
lit and door
Page Turn: Page turn
Roll: Ro
ll
Frame I/O: Frame i
n/out
Resizer Slide / Squeeze: Resiz
er slide and squeeze
Resizer Frame I/O:
Resizer frame in/out
For 2-channel mode
Select from the following DME wipe pattern groups.
Page Turn: Page turn
Roll: Ro
ll
3 Set the button for the target wipe pattern to the on
state.
Setting Independent Key Transition
DME Wipe Modifiers
For details about the supported modifiers, see “Setting
Modifiers” (page 167).
Setting the DME wipe direction (Direction)
1 Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2 In the [Direction] group, select a DME wipe
direction.
Normal: DME
wipe in normal direction.
Normal/Reverse: Alte
rnate directions between
normal and reverse after each transition.
Reverse: DME wipe
in the opposite direction of the
normal direction.
Modifying a DME wipe pattern edge
(Edge)
1 Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2 In the [Edge] group, select a type of edge.
Border: Adds a
border to a pattern.
Soft Border: So
ftens a border applied to a pattern.
When the [Border] button is selected, set the
foll
owing parameters.
When the [Soft Border] button is selected, set the
following parameters.
Note
No. Parameter Adjustment
1 Width Border width
3 Luminance Luminance
4 Saturation Saturation
5 Hue Hue
No. Parameter Adjustment
1 Width Border width
2 Inner Soft Softness of inner edge of
bo
rder
3 Luminance Luminance
4 Saturation Saturation
5 Hue Hue
