Suzuki DF 50 Service Manual

GENERAL INFORMATION 1-6
SPECIFICATIONS
Item Unit
Data
DF40T DF50T
DIMENSIONS & WEIGHT
Overall length (front to back)
mm (in.) 756 (29.8)
Overall width (side to side)
mm (in.) 382 (15.0)
Overall height S
mm (in.) 1263 (49.7)
L
mm (in.) 1390 (54.7)
Weight
(without engine oil)
S
kg (Ib.) 106 (234)
L
kg (Ib.) 109 (240)
Transom height S
mm (in. type) 401 (15)
L
mm (in. type) 528 (20)
PERFORMANCE
Maximum output kW (PS) 29.4 (40)
Recommended operating range
r/min
Idle speed
r/min
36.8 (50)
5200 – 5800
5900 – 6500
850 ± 50 (in-gear: approx. 850±50)
POWERHEAD
Engine type 4-stroke DOHC
Number of cylinders
3
Bore
mm (in.) 71.0 (2.80)
Stroke mm (in.) 68.6 (2.70)
Total displacement
cm
3
(cu in.) 815 (49.7)
Compression ratio
: 1 10
Spark plug NGK DCPR6E
Ignition system
Full-transistorized ignition
Fuel supply system
Multi-point sequential electronic fuel injection
Exhaust system Through prop exhaust
Cooling system
Water cooled
Lubrication system
Wet sump by trochoid pump
Starting system Electric
Throttle control
Remote control
PRE-FIX 04001F 05001F

Suzuki DF 50 Specifications

General

Engine Type	4-Stroke
Cylinders	3
Displacement	941 cc
Starting System	Electric
Steering	Remote
Engine Type Detail	DOHC 12-Valve
Maximum Output	50 HP
Ignition System	Digital CDI
Alternator	12V 19A
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Trim Method	Power Trim and Tilt
Max Power	50 HP
Alternator Output	12V 19A
Fuel Delivery System	Sequential Multi Point Electronic Fuel Injection
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Engine Oil Capacity	2.7 L
Full Throttle RPM Range	5300 - 6300 RPM
Oil Capacity	2.7 L
Bore x Stroke	72.5 x 76.0 mm (2.85 x 2.99 in.)
