Suzuki DF 50 Service Manual

ELECTRICAL 4-8
INSPECTION
IGNITION SWITCH
09930-99320 : Digital tester
Tester range : (Continuity)
1. Disconnect the ignition switch from remo-con box wiring
harness.
2. Check continuity between wiring leads at the key positions
shown in the chart.
z
If out of specification, replace ignition switch.
Key
Position
11
11
1 OFF
Switch Lead Wires
Black Green White Gray Brown Orange
22
22
2 ON
33
33
3 START
44
44
4 FREE
55
55
5 PUSH
: Continuity
Black
Green
White
Gray
Orange
Brown
1 (OFF)
2 (ON)
3 (START)
4 (FREE)
5 (PUSH)
PUSH
r

Suzuki DF 50 Specifications

General

Engine Type	4-Stroke
Cylinders	3
Displacement	941 cc
Starting System	Electric
Steering	Remote
Engine Type Detail	DOHC 12-Valve
Maximum Output	50 HP
Ignition System	Digital CDI
Alternator	12V 19A
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Trim Method	Power Trim and Tilt
Max Power	50 HP
Alternator Output	12V 19A
Fuel Delivery System	Sequential Multi Point Electronic Fuel Injection
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Engine Oil Capacity	2.7 L
Full Throttle RPM Range	5300 - 6300 RPM
Oil Capacity	2.7 L
Bore x Stroke	72.5 x 76.0 mm (2.85 x 2.99 in.)
