14 DF40/50 “K6” (’06) MODEL
ECM
The ECM has been changed in program.
FUEL FILTER
A new style fuel filter will be used that provides a drain feature.
This new filter requires several new components shown below and a new mounting bracket to retain the fil-
ter onto the outboard.
Inspect the fuel filter regularly.
If any water and impurities exists in the fuel filter, remove the drain cap and drain the water and impurities.
IAC HOSE
The inhalation location of air of IAC was changed from silencer case to atmospherer.
The IAC hose has been changed in length and routing.
The silencer cap, IAC hose clamp, hose clamp and clamp bolt have also been added.
Fuel filter bracket
Fuel filter
Fuel filter
Clip
Drain cap
Fuel fiter clamp
Fuel filter bracket
IAC hose
IAC valve silencer
IAC hose
IAC valve silencer
Silencer cap

Suzuki DF 50 Specifications

General

Engine Type	4-Stroke
Cylinders	3
Displacement	941 cc
Starting System	Electric
Steering	Remote
Engine Type Detail	DOHC 12-Valve
Maximum Output	50 HP
Ignition System	Digital CDI
Alternator	12V 19A
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Trim Method	Power Trim and Tilt
Max Power	50 HP
Alternator Output	12V 19A
Fuel Delivery System	Sequential Multi Point Electronic Fuel Injection
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Engine Oil Capacity	2.7 L
Full Throttle RPM Range	5300 - 6300 RPM
Oil Capacity	2.7 L
Bore x Stroke	72.5 x 76.0 mm (2.85 x 2.99 in.)
