Suzuki DF 50 - Service Data

6 DF40/50 “K7” (’07) MODEL
SERVICE DATA
POWERHEAD
** Figures shown are guidelines only, not absolute service limits.
ENGINE OIL PUMP
Item Unit
Data
DF40 DF50
Recommended
operating range
Except E01
r/min
5 200 – 5 800
5 900 – 6 500
E01 5 600 – 6 200
Idle speed r/min 850 ± 50 (in-gear: approx. 850)
**Cylinder compression kPa
(kg/cm
2
, psi)
1 300 – 1 600 (13 – 16, 185 – 228)
**Cylinder compression max.
difference between any other
cylinders
kPa
(kg/cm
2
, psi)
100 (1.0, 14)
**Engine oil pressure kPa
(kg/cm
2
, psi)
300 – 380 (3.0 – 3.8, 43 – 54) at 4 000 r/min
(at normal operating temp.)
Engine oil API classification SE, SF, SG, SH, SJ
Viscosity rating SAE 10W-40
Engine oil amounts
L (US/lmp. qt)
2.2 (2.3/1.9) : Oil change only
2.4 (2.5/2.1) : Oil filter change
Thermostat operating temperature °C (°F) 58 – 62 (136 – 144)
Radial clearance Limit mm (in) 0.31 (0.012)
Side clearance Limit mm (in) 0.15 (0.006)
