HOW TO USE THIS MANUAL
TO LOCATE WHAT YOU ARE
LOOKING FOR:
1. The text of this manual is divided into sections.
2. The section titles are listed on the previous page
in a GROUP INDEX. Select the section you wish
to reference.
3. Holding the manual as shown at the right will al-
lowyou to find the first page of the section easily.
4. The first page of each section lists a table of con-
tents to easily locate the item and page you need.
COMPONENT PARTS AND IMPORTANT ITEM ILLUSTRATIONS
Under the name of each system or unit, an exploded view is provided with work instructions and other
service information such as the tightening torque, lubrication and locking agent points.
Example :
1Flywheel bolt
2Washer
3Key
4Flywheel
5CKP sensor
6Screw
7CMP sensor
8Bolt
1
2
3
4
5
5
5
6
7
8
Crankshaft
@ 200 N
.
m
(20.0 kg-m, 145 lb.-ft.)
o
h
NOTE:
Clean flywheel and crankshaft mating
surfaces with cleaning solvent.
To Next Page
