Suzuki DF 50 Service Manual

2-19 PERIODIC MAINTENANCE
BATTERY
Inspect every 50 hours (3 months)
A
• Never expose battery to open flame or electric spark
as batteries generate gas, which is flammable and
explosive.
• Battery acid is poisonous and corrosive. Avoid con-
tact with eyes, skin, clothing, and painted surfaces.
If battery acid comes in contact with any of these,
flush immediately with large amounts of water.
If acid contacts the eyes or skin, get immediate medi-
cal attention.
• Batteries should always be kept out of reach of chil-
dren.
• When checking or servicing the battery, disconnect
the negative (black) cable. Be careful not to cause a
short circuit by allowing metal objects to contact the
battery posts and the motor at the same time.
• Wear approved eye protection.
Recommended battery :
12 V 70 Ah (252 kC) or larger
CONNECTING BATTERY
Upon completion of connection, lightly apply grease to the bat-
tery terminals.
How to connect :
(1) Connect the positive (+) terminal first.
(2) Connect the negative (–) terminal second.
How to disconnect :
(1) Disconnect the negative (–) terminal first.
(2) Disconnect the positive (+) terminal second.

Suzuki DF 50 Specifications

General

Engine Type	4-Stroke
Cylinders	3
Displacement	941 cc
Starting System	Electric
Steering	Remote
Engine Type Detail	DOHC 12-Valve
Maximum Output	50 HP
Ignition System	Digital CDI
Alternator	12V 19A
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Trim Method	Power Trim and Tilt
Max Power	50 HP
Alternator Output	12V 19A
Fuel Delivery System	Sequential Multi Point Electronic Fuel Injection
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Engine Oil Capacity	2.7 L
Full Throttle RPM Range	5300 - 6300 RPM
Oil Capacity	2.7 L
Bore x Stroke	72.5 x 76.0 mm (2.85 x 2.99 in.)
