Suzuki DF 50 Service Manual

LOWER UNIT 9-10
DRIVESHAFT BEARING HOUSING
• Inspect housing. Replace if cracked or damaged.
• Inspect bearing. Replace if pitted, noisy or rough.
• Check condition of oil seals. Replace if nicked, cut or worn.
Replacing driveshaft oil seal
1. Using bearing remover, draw the driveshaft bearing out of
the driveshaft housing.
09923-74510 : Bearing remover
2. With the oil seal remover, draw the two oil seals out of the
driveshaft bearing housing.
09913-50121 : Oil seal remover
3. Apply Water Resistant Grease to the inner circumference of
the driveshaft bearing housing.
99000-25160 : Water Resistant Grease
4. Grease the inner lips of the seal.
With the lips facing away from driveshaft bearing, place seal
in position and drive it into the bearing housing.
5. Place the driveshaft bearing in position and drive it into the
bearing housing.
l
z
z
Direction of
water pump case

Suzuki DF 50 Specifications

General

Engine Type	4-Stroke
Cylinders	3
Displacement	941 cc
Starting System	Electric
Steering	Remote
Engine Type Detail	DOHC 12-Valve
Maximum Output	50 HP
Ignition System	Digital CDI
Alternator	12V 19A
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Trim Method	Power Trim and Tilt
Max Power	50 HP
Alternator Output	12V 19A
Fuel Delivery System	Sequential Multi Point Electronic Fuel Injection
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Engine Oil Capacity	2.7 L
Full Throttle RPM Range	5300 - 6300 RPM
Oil Capacity	2.7 L
Bore x Stroke	72.5 x 76.0 mm (2.85 x 2.99 in.)
