DF40/50 “K6” (’06) MODEL 15
IAC HOSE ROUTING
INTAKE MANIFOLD
The intake manifold has been changed in shape and the plug and gasket have been eliminated.
IAC hose clamp
Clamp bolt
IAC hose clamp
IAC hose
Hose clamp
ECM
Plug
Gasket
