2-5 PERIODIC MAINTENANCE
GEAR OIL
Change initially after 20 hours (1 month) and every 100
hours (6 months) thereafter.
(1) Place the outboard motor upright on a level surface.
(2) Place a container under the lower unit.
(3) Remove the lower gear oil drain plug before the gear oil
level plug and drain the gear oil.
1
2
1 Oil level plug
2 Oil drain plug
(4) Fill with the recommended gear oil through the oil drain hole
until oil just starts to flow out from the oil level hole.
Gear oil amount : 610 ml ( 20.6 / 21.5 US / Imp. oz)
Recommended oil :
Suzuki Outboard Motor Gear Oil or SAE # 90
Hypoid gear oil
(5) Install the oil level plug before removing the oil filler tube
from the drain hole.
(6) Install the oil drain plug.
B
Do not re-use gaskets. Always use a new gasket.
