wsm ME8200 User Manual

2-S1
ME8200, ME9000, WSM
CLUTCH
1. TROUBLESHOOTING
TRAVELLING CLUTCH
W1014322
PTO CLUTCH
W1010896
Symptom Probable Cause Solution
Reference
Page
Shuttle Clutch Slip Operating pressure is low Adjust 8-S9
Shuttle clutch valve malfunctioning Repair or replace 8-S9
Clutch disc or steel plate excessively worn Replace 3-S30
Deformation of piston or steel plate Replace 3-S30
Shuttle Clutch
Operating Pressure
Is Low
Transmission oil improper or insufficient Replenish or change G-8, 16
Shuttle clutch valve malfunctioning Repair or replace 8-S9
Shuttle Clutch Drags Return spring weaken or broken Replace 3-S25
Modulating valve malfunctioning Replace –
Deformation of piston or steel plate Replace 3-S30
Tractor Does Not
Keep in Neutral
Shuttle linkage defective or deformed Adjust or replace 8-S10 to 15
PTO Clutch Slip Operating pressure is low Adjust 8-S8
PTO clutch valve malfunctioning Repair or replace 2-S23, 26
Clutch disc or steel plate excessively worn Replace 2-S29
Deformation of piston or return spring Replace 2-S30
PTO Shaft Does Not
Rotate
PTO clutch malfunctioning Repair or replace 2-S27
PTO propeller shaft coupling disengaged Engage –
PTO Clutch
Operating Pressure
Is Low
Transmission oil improper or insufficient Replenish or change G-8, 16
Relief valve malfunctioning Adjust or replace 8-S8
PTO Clutch Drags Brake plate excessively worn Replace 2-S28
Return spring weaken or broken Replace 2-S30
Modulating valve malfunctioning Repair or replace 2-S28
Deformation of plate or steel plate Replace 2-S30
