3-S2
ME8200, ME9000, WSM
TRANSMISSION
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Shift Fork to Shifter Groove Clearance 0.13 to 0.40 mm
0.0051 to 0.0157 in.
0.8 mm
0.031 in.
Spiral Bevel Pinion Shaft Turning Torque 3.14 to 3.63 N·m
0.32 to 0.37 kgf·m
2.31 to 2.68 lbf·ft
–
Spiral Bevel Pinion Shaft and Differential
Assembly
Turning Torque 5.59 to 6.67 N·m
0.57 to 0.68 kgf·m
4.12 to 4.92 lbf·ft
–
Spiral Bevel Gear to Spiral Bevel Pinion
Shaft
Backlash 0.20 to 0.30 mm
0.0079 to 0.0118 in.
0.4 mm
0.016 in
Differential Case Bore (Differential Case
Cover Bore) to Differential Side Gear Boss
Clearance 0.070 to 0.169 mm
0.00276 to 0.00665 in.
0.35 mm
0.014 in.
Differential Case
Bore
(I.D.)
49.070 to 49.150 mm
1.93189 to 1.93504 in.
–
Differential Case
Cover Bore
(I.D.)
49.070 to 49.150 mm
1.93189 to 1.93504 in.
–
Differential Side
Gear Boss
(O.D.)
48.961 to 49.000 mm
1.92760 to 1.92913 in.
–
Differential Pinion Shaft to Differential
Pinion
Clearance 0.080 to 0.122 mm
0.00315 to 0.00480 in.
0.25 mm
0.0098 in.
Differential Pinion
Shaft
(I.D.)
25.939 to 25.960 mm
1.02122 to 1.02205 in.
–
Differential Pinion
(O.D.)
26.040 to 26.061 mm
1.02520 to 1.02602 in.
–
Differential Pinion to Differential Side Gear Backlash 0.15 to 0.30 mm
0.0059 to 0.0118 in.
0.4 mm
0.016 in.
Differential Lock Pedal (Front) Free Travel 20.0 to 30.0 mm
0.79 to 1.18 in.
–
Differential Lock Shifter Clearance 1.0 to 1.5 mm
0.0394 to 0.0591 in.
–
Main Speed Change Rod 1 Length (ROPS) 457 mm
17.99 in.
–
KiSC issued 03, 2007 A
