4-S2
ME8200, ME9000, WSM
REAR AXLE
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Main Speed Change Rod 1 (ROPS) Length 457 mm
17.99 in.
–
Internal Gear to Planetary Gear Backlash 0.08 to 0.30 mm
0.0032 to 0.0118 in.
0.5 mm
0.020 in.
Planetary Gear Thrust Collar Thickness 1.55 to 1.65 mm
0.0610 to 0.0650 in.
1.2 mm
0.047 in.
Planetary Gear to Planetary Gear Shaft Clearance 0.009 to 0.048 mm
0.00035 to 0.00189 in.
0.30 mm
0.0118 in.
Planetary Gear
Shaft O.D.
31.989 to 32.000 mm
1.25941 to 1.25984 in.
–
Planetary Gear
I.D.
39.000 to 39.025 mm
1.53543 to 1.53641 in.
–
Needle O.D. 3.494 to 3.500 mm
0.13756 to 0.13780 in.
–
Auxiliary Control Lever to Stopper (ROPS) Clearance 0 to 1 mm
0 to 0.039 in.
–
To Next Page
