3-S4
ME8200, ME9000, WSM
TRANSMISSION
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-10.)
W1012736
Item N·m kgf·m lbf·ft
Main delivery pipe and return pipe retaining nut 47.1 to 51.0 4.8 to 5.2 34.7 to 37.6
Turning delivery hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Engine and clutch housing mounting screw, nut 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Engine and clutch housing mounting stud bolt 38.2 to 45.1 3.9 to 4.6 28.2 to 33.3
Cover mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Transmission case and clutch housing mounting screw,
nut (M12, grade 9 nut)
103.0 to 117.7 10.5 to 12.0 75.9 to 86.8
Transmission case and clutch housing mounting screw,
nut (M12, grade 7 screw)
77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Speed change cover mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Bearing holder mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Bearing holder 2 mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.7 to 224.2
Hydraulic cylinder assembly mounting screw and nut 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Rear axle case mounting screw and nut 123.6 to 147.1 12.6 to 15.0 91.1 to 108.5
PTO gear case assembly mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
PTO shaft staking nut 225.6 to 264.8 23 to 27 166.4 to 195.3
PTO gear case cover mounting screw, reamer screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Differential bearing support mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Differential case cover mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Spiral bevel gear UBS screw 142.2 to 161.8 14.5 to 16.5 104.9 to 119.3
PTO clutch valve mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
PTO clutch holder mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Spiral bevel pinion shaft staking nut 93.2 to 103.0 9.5 to 10.5 68.7 to 75.9
Starter's terminal B mounting nut 9.8 to 11.8 1.0 to 1.2 7.2 to 8.7
Shuttle case mounting screw (M8, grade 9) 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Shuttle case mounting nut 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Bonnet support mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Fender bracket mounting bolt 197 to 227 20 to 23 145 to 167
Step mounting screw (M16) 117.7 to 147.1 12.0 to 15.0 86.8 to 108.5
Delivery pipe nut 108 to 117 11.0 to 12.0 79.6 to 86.8
PTO shuttle pipe nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Shuttle pipe eye joint bolt 39.2 to 45.0 4.0 to 4.6 29.0 to 33.2
KiSC issued 03, 2007 A
