2-S3
ME8200, ME9000, WSM
CLUTCH
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-10.)
W1012736
Item N·m kgf·m lbf·ft
Power steering main delivery pipe and return pipe
retaining nut
47.1 to 51.0 4.8 to 5.2 34.7 to 37.6
Power steering turning delivery hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Starter's B terminal mounting nut 9.8 to 11.8 1.0 to 1.2 7.2 to 8.7
Engine and clutch housing mounting screw, nut 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Engine and clutch housing mounting stud bolt 38.2 to 45.1 3.9 to 4.6 28.2 to 33.3
PTO clutch valve mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
PTO clutch holder mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Brake plate mounting screw 9.8 to 11.3 1.00 to 1.15 7.2 to 8.3
Rear wheel mounting nut 260 to 304 26.5 to 31.0 192 to 224
Bonnet support mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Damper disc mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
PTO shuttle pipe nut 49.5 to 68.6 5.0 to 7.0 36.2 to 50.6
Cover mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Fender bracket mounting bolt 197 to 227 20 to 23 145 to 167
Step mounting screw, M16 117.7 to 147.1 12.0 to 15.0 86.8 to 108.5
Transmission case and clutch housing mounting screw
and nut (M12, grade 9 nut)
103.0 to 117.7 10.5 to 12.0 75.9 to 86.8
Transmission case and clutch housing mounting screw
and nut (M12, grade 7 screw)
77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Delivery pipe nut 108 to 117 11.0 to 12.0 79.6 to 86.8
Shuttle pipe eye joint bolt 39.2 to 45.0 4.0 to 4.6 29.0 to 33.2
To Next Page
