wsm ME8200 User Manual

10-S7
ME8200, ME9000, WSM
CABIN
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
A/C Compressor Magnet Clutch Air-gap 0.25 to 0.50 mm
0.01 to 0.02 in.
–
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure
Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
–
Pressure
(HI Pressure Side)
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure
Side)
Less than
approx. 0.196 MPa
2.0 kgf/cm
2
28.4 psi
–
Setting Pressure
(HI Pressure Side)
More than
approx. 3.14 MPa
32 kgf/cm
2
455 psi
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.39 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Hydraulic Control Rod
Position and Draft Rod
Length Approx. 264 mm
10.39 in.
–
KiSC issued 03, 2007 A
