2-S2
ME8200, ME9000, WSM
CLUTCH
2. SERVICING SPECIFICATIONS
TRAVELLING CLUTCH
W1013874
PTO CLUTCH
W1011259
Item Factory Specification Allowable Limit
Clutch Pedal Free Travel 15 to 25 mm
0.59 to 0.98 in.
–
Total Stroke 165 to 170 mm
6.5 to 6.7 in.
–
Damper Disc Boss to Gear Shaft Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
PTO Clutch Disc Thickness 1.70 to 1.90 mm
0.067 to 0.075 in.
1.55 mm
0.061 in.
PTO Steel Plate Thickness 1.15 to 1.25 mm
0.045 to 0.075 in.
1.10 mm
0.043 in.
PTO Piston Flatness – 0.15 mm
0.006 in.
PTO Steel Plate Flatness – 0.30 mm
0.012 in.
PTO Return Spring Free Length 40.5 mm
1.59 in.
37.5 mm
1.48 in.
PTO Brake Spring Free Length 20.3 mm
0.80 in.
18.0 mm
0.71 in.
Seal Ring Thickness 2.45 to 2.50 mm
0.096 to 0.098 in.
2.0 mm
0.079 in.
Main Speed Change Rod 1 Length 457 mm
17.99 in.
–
KiSC issued 03, 2007 A
