5-S2
ME8200, ME9000, WSM
BRAKES
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 7 to 14 mm
0.28 to 0.55 in.
–
Stroke (RH and
LH)
Less than 100 mm
3.9 in.
–
Difference of
Stroke
(RH and LH)
0 to 5 mm
0 to 0.20 in.
–
Brake Piston Flatness – 0.3 mm
0.012 in.
Cam Plate Flatness – 0.3 mm
0.012 in.
Cam Plate and Ball Height 25.45 to 25.55 mm
1.0020 to 1.0059 in.
25.00 mm
0.9843 in.
Brake Disc Thickness 4.15 to 4.35 mm
0.1634 to 0.1713 in.
3.3 mm
0.130 in.
Plate Thickness 2.25 to 2.35 mm
0.0886 to 0.0925 in.
1.5 mm
0.059 in.
Parking Brake Wire Length of Thread
(Lower Side)
10 mm
0.39 in.
–
Projection Length
of Thread (Upper
Side)
0 to 1 mm
0 to 0.039 in.
–
To Next Page
