Zebra ZD620 User Manual

205
Print Operations
Darkness Control
The Darkness Control switch allows the operator to modify the darkness setting for minor
variations in media and printers avoiding the need to change the program or driver settings
sent to the printer.
The control switch has three (3) settings:
• Left (Low - Default): no effect .
• Middle (Medium): increases ZPL darkness 3 levels.
• Right (High): increases ZPL darkness 6 levels.
The Low (default) setting makes no change to the actual Darkness setting as set by
programming or driver setting. The Medium setting increases the Darkness level by 3, i.e.
if the printer is set to the default darkness level of 20, then the actual darkness applied
while printing will be 23. The High setting will add six (6) darkness levels to the set
darkness level.
Important • Setting the Darkness too high or too low may reduce barcode readability.
Darkness Control

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
