Zebra ZD620 User Manual

23
Introduction
Modes of Printing
You can operate this printer in many different modes and media configurations:
• Direct thermal printing (which uses heat sensitive media to print).
• Thermal transfer printing with easy to use thermal transfer ribbon cartridge or rib-
bon rolls (heat and pressure transfers ink from the ribbon to media).
• Standard Tear-Off mode allows you to tear off each label/receipt or batch print a
strip of labels and tear them off after it is printed.
• Label Dispense Mode: If an optional dispenser is installed, the backing material
can be peeled away from the label as it is printed. After this label is removed, the
next one is printed.
• Media Cutting: If an optional media cutter is installed, the printer can cut the label
liner between labels, receipt paper or tag stock.
• Linerless media printing with Cut or Tear-Off label options for easy pick and place
label applications.
• Stand-alone: The printer can print without being directly connected to a computer.
• A printer with the color LCD display option can use menus to access and print
a label format/form.
• A Link-OS App connecting via Bluetooth (Wireless option).
• An auto running label format/form (programming based).
• A data input device connected to the printer’s USB Host port or serial port.
This mode accommodates data input devices, such as scanners, weigh
scales, a Zebra Keyboard Display Unit (ZKDU), etc.
• Shared network printing: Printers configured with Ethernet (LAN) and Wi-Fi
interface options include an internal print server.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
