Zebra ZD620 User Manual

303
Tools
Reset Button
In addition to the power on configurations described previously, the ZD-Series printer has
a dedicated reset button located on the bottom of the printer which can be pressed with a
paperclip or similar small object.
Pressing the button has the following results based on the length of the button press:
0-1 second No action
1-5 seconds Printer reset – Printer performs a factory reset and will automatically
print a configuration label (and network label if present)
6-10 seconds Network reset – Printer drops connection to the network, and a
network factory default reset occurs. Upon completion of the reset, a
configuration and network configuration label are automatically
printed.
More than 10 seconds Exits the factory defaults function without resetting the printer or
making changes
Reset Access Hole

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
