Zebra ZD620 User Manual

64
Controls and Indicators
Ribbon In (Ribbon Cartridge Printers Only)
thermal transfer printer is in Direct Thermal Mode
and has a ribbon cartridge installed. Remove the
ribbon cartridge to continue printing in direct
thermal mode.
Transferring Data
Data communications are in process.
Data Transfers Paused
A data communication operation has not finished,
but is not actively being transferred.
Out of Memory
Out of memory while storing content (formats,
graphics, fonts, etc.).
Cover Open/Printhead (PH) Open
The cover (printhead) is open. The printer needs
attention and cannot continue without user
intervention.
Cut Error (Binding)
The cutter blade is bound and is not moving
properly.
Cartridge Authentication Failed
The ribbon cartridge can not be authenticated or
has been altered. The printer only supports
Genuine Zebra Ribbon Cartridges and does not
support refurbished or non-Zebra cartridges.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
