Zebra ZD620 User Manual

53
Install Hardware Options
Print Resolution Upgrade Kits
There are four (4) print resolution upgrade kits. The same procedure is used to change all
the printhead resolution upgrade kits. Both the printhead and platen (drive) rollers must be
changed and are resolution dependent. The printer automatically detects the change in
printheads and the platen roller materials are identified by color.
• Standard Printing
• Change the printer from 203 dpi to 300 dpi printing.
• Change the printer from 300 dpi to 203 dpi printing.
• Linerless Printing (for Direct Thermal ZD620 printers only)
• Change the printer from 203 dpi to 300 dpi printing.
• Change the printer from 300 dpi to 203 dpi printing.
Printheads used in the upgrade kits include a 203 or 300 marking to help you keep the
unpackaged upgrade printhead separate from the original printhead. The original
printhead contains no marking identifying its print resolution.
The platen (drive) rollers are colored differently to help you keep from accidentally using
the old platen roller. See Identifying Platen Drive Rollers Types
Installing the Printhead Resolution Upgrade Kits
1. Turn the printer off and disconnect the power.
2. Use the platen roller replacement procedure. See Platen Cleaning and Replacement
3. Use the printhead replacement procedure. See Replacing the Printhead
4. Re-attach power and turn the printer on. The printer will automatically detect the
change in printhead (but not the platen) when the printer verifies the printer’s
configuration.
Important • For best results and the latest printer features and operation, download and
install the latest printer firmware. See Updating Printer Firmware.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
