Zebra ZD620 User Manual

242
Maintenance
Cutter Option
Interval: Not an operator serviceable component. Do Not Clean inside the cutter opening
or blade mechanism. You may use the Exterior cleaning to clean the cutter bezel
(housing).
Method: Call a service technician.
Procedure: None
Cut Warning • There are no operator serviceable parts in the cutter unit. Never remove
the cutter cover (bezel). Never attempt to insert objects or fingers in to the cutter
mechanism.
Important • The blade has a special coating to resist adhesives and wear. Cleaning it may
ruin the blade.
Important • Using un-approved tools, cotton swabs, solvents (including alcohol), etc.; all
may damage or shorten the cutter’s usable life or cause the cutter to bind.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
