Zebra ZD620 User Manual

285
Troubleshooting
Alert: PRINTHEAD UNDER TEMP
1. The printhead is below operating temperature for proper printing.
Possible Cause - 1
The ambient temperature at the printers location is below the specified operating range.
Resolution
Turn the printer off. Move the printer location and wait for it to warm naturally. Moisture may
condense in and on the printer if the temperature changes too quickly.
Possible Cause - 2
The printhead thermistor has failed.
Resolution
1 — Turn the printer off by holding the power using the POWER button down for 5
seconds. Wait for thee printer to shutdown completely. Turn the printer on.
2 — If the printer does not recover from this error, call a service technician.
PRINTHEAD UNDER TEMP
PRINTING HALTED
THERMISTOR
REPLACE PRINTHEAD

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
