Zebra ZD620 User Manual

246
Maintenance
Media Path Cleaning
Use a cleaning swab and/or a lint free cloth to remove debris, dust or crust that has built-
up on the holders, guides and media path surfaces. Lightly moisten the swab or cloth with
99% solution medical-grade alcohol. For hard to clean areas, use extra alcohol on a
cleaning swab to soak the debris to break up any adhesive that may have accumulated on
surfaces in the media compartment.
Do not clean the printhead, sensors, or platen as part of this process.
Lower Half of ZD60/ZD420 Printers
The lower half of these printers these printers get cleaned the same.
1. Wipe the inside surfaces of the roll holders and the underside of the media guides
with a cleaning swabs and wipes.
2. Wipe the movable sensor slide channel (but not sensor). Move the sensor to get to all
areas.
3. Wait one minute before closing the printer. Discard used cleaning supplies.
Media Guides
Media Roll Holders
Don’t Clean Sensor

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
