Zebra ZD620 User Manual

293
Troubleshooting
3 — If the printer does not recover from this error, call a service technician. This is not a
user serviceable item.
Issue: Non-continuous labels act as Continuous labels.
A non-continuous label format with matching media loaded in the printer, was sent to the
printer but prints like it is continuous media.
Possible Cause - 1
The printer was not calibrated for the media being used.
Possible Cause - 2
The printer is configured for continuous media.
Resolution
Set the printer for the correct media type (gap/notch, continuous, or mark) and calibrate
the printer using Run a SmartCal Media Calibration, if necessary use Manual Media
Calibration for hard to calibrate media types. See MEDIA TYPE (SETTINGS menu item)
for ZD620 printers with the display to check and set media type.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
