Zebra ZD620 User Manual

255
Maintenance
Platen Cleaning and Replacement
The platen (drive roller) normally does not require cleaning. Normally, paper and liner dust
can accumulate without affecting print operations.
Clean the platen (and media path) whenever the printer has significantly poorer
performance, print quality or media handling. The platen is the print surface and drive roller
for your media. If sticking or jamming continues even after cleaning, you must replace the
platen.
Important • Contaminants on the platen roller can damage the printhead or cause the
media to slip or stick when printing. Adhesive, dirt, general dust, oils and other
contaminants should be cleaned immediately off the platen.
Important • LINERLESS PLATENS — Do not wash or scrub. Only remove adhesive
particles by using the adhesive side of linerless media. Lightly touch the platen roller with
a linerless label to lift particles off the exposed area of the platen roller and the media path
areas.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
