BMW R 1150 RT Repair Manual

11.36
11 11 Removing alternator mount cover
•
Remove the alternator.
•
Install locking device, BMWNo.115640, to
lock clutch housing.
•
Remove pulley (1).
L Note:
It is not necessary to remove magnetic gate (2) when
removing the alternator mount cover as a unit.
•
Remove magnetic gate (2).
•
Remove alternator mount cover (3).
11 11 047
Replacing radial shaft seal in
alternator mount cover
•
Carefully lever out radial shaft seal, using a
screwdriver.
L Note:
Slide new radial shaft seal over taper on sliding
sleeve, pre-shape and pull off.
•
Drive in the new radial shaft seal with drift and
sliding sleeve, BMW No. 11 5 680.
R22110050
3
2
1
11 5 640
11 5 680
RS110240

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
