How to use this manual
Each chapter starts with the list of contents.
The list of contents is followed by the Technical Data table.
Key to symbols
In this Repair Manual for the R 1150 RT model, the following symbols are used; their meanings are ex-
plained in the table.
Special instructions aimed at improving the work procedures
L Note:
Specific information on operating, inspecting and adjusting work for the motorcycle as well as maintenance
procedures.
e Attention:
Instructions and precautions specifically intended to prevent damage to the motorcycle. Failure to comply
with them could invalidate the warranty.
d Warning:
This symbol stands for precautions and measures which are essential in order to protect the rider or other
persons from possibly severe or fatal injury.
Contents
The titles of the tasks described in this chapter............. complete with page numbers
Activities
•
Activities
•
The bullet symbol means that work steps are described in greater detail under a headline
– preceding activities
– A line indicates work steps described in greater detail under another headline or in another chapter
If the term “undo” or “remove” is used:
the fastener (e.g. screw) must be slackened off and taken out
or
a component (e.g. fuel rail) must be removed to the extent that other components which it conceals (e.g.
throttlevalve rail) are accessible
If the term “loosen” or “slacken” is used
the fastener (e.g. screw) must only be slackened off but not taken out
X Tightening torque:
Values are stated if they differ from DIN EN 24 014 or DIN 912 ISO industrial standards.
