BMW R 1150 RT Repair Manual

11.39
11 11 Removing radial shaft seal on
crankshaft with engine installed
•
Install locking device, BMW No. 11 5 640, to
lock clutch housing.
•
Remove the clutch.
e Attention:
Take care not to damage the sealing faces of crank-
case and crankshaft.
•
Carefully lever out radial shaft seal, using a
screwdriver.
L Note:
The radial shaft seals can be lifted out when the
crankcase is disassembled.
•
Using awl, BMWNo.008583, carefully punch a
hole in the shaft sealing ring.
•
Screw the pull rod, BMWNo.008581, into the
hole and use impact weight, BMWNo.008582,
to remove the shaft sealing ring.
S210010
11 5 640
S110040
S110100
00 8 583
00 8 582
00 8 581

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
