00.8
Model R 1150 RT
Connection
33 Rear wheel drive
Crown gear and pinion assembly
Oil filler plug Nm 23
Oil drain plug Nm 23
Threaded ring Nm 160
(clean thread + Loctite 577)
Hexagon nut, input bevel gear Nm
200
(clean thread + Loctite 2701)
Cover to final drive housing Nm 35
Swinging arm
Reaction link to final-drive unit Nm 43
(load approx. 85 kg/approx. 187 lbs) onto mo-
torcycle and tighten loose reaction link)
Fixed bearing stud bolt,
swinging arm to right rear axle housing
Nm 160
(clean thread + Loctite 2701)
Floating bearing stud bolt,
swinging arm to left rear axle housing
1. Initial torque Nm 9
2. Slacken
3. Final torque Nm 7
(clean thread + Loctite 2701)
Lock nut, floating bearing stud bolt,
swinging arm to left rear axle housing
Nm 160
Fixed bearing stud bolt,
swinging arm to right of gearbox
Nm 160
(clean thread + Loctite 2701)
Floating bearing stud bolt,
swinging arm to left of gearbox
1. Initial torque Nm 9
2. Slacken
3. Final torque Nm 7
(clean thread + Loctite 2701)
Lock nut, floating bearing stud bolt,
swinging arm to left of gearbox
Nm 160
Spring strut
Spring strut to rear frame Nm 50
Spring strut to rear swinging arm Nm 58
(clean thread + Loctite 243)
Hydraulic spring adjuster to rear frame Nm 22
