BMW R 1150 RT Repair Manual

46.22
46 52 Removing and installing main
(centre) stand
•
Remove side stand.
•
Secure stand, BMWNo.001520, to motorcycle
with bushes and screws, BMWNo.001529.
•
Disengage tension springs.
•
Remove right and left bearing bushings (1).
•
Remove the main (centre) stand.
•
Remove right and left bearing blocks (2).
•
Installation is the reverse of the removal proce-
dure.
L Note:
When installing the springs, make sure that the thick
spring is on the inside and the thin spring on the
outside (arrow).
Lubricant:.................. e.g. Staburags NBU 30 PTM
1
v
R22460090
1
2
00 1 529
R28110060
00 1 520
R21460150

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
