BMW R 1150 RT Repair Manual

16.6
16 11 Removing and installing roll-
over valve
e Attention:
Fuel is flammable and a hazard to health.
Observe all applicable safety regulations.
•
Remove side panels.
•
Remove the fuel filler cap.
•
Remove tank cover.
•
Remove the reducer unit with roll-over valve (1).
•
Release the hose clips with pliers,
BMW No. 17 5 500, and disconnect hoses.
•
Remove the reducer unit with roll-over valve.
•
Remove the roll-over valve.
•
Installation is the reverse of the removal proce-
dure.
•
Secure hose clips with pliers,
BMW No. 17 5 500.
e Attention:
Fit a new O-ring (2) if necessary.
Make sure that the O-ring seal is correctly seated.
After installing, check fuel filler cap for leaks.
6x
6x
R22160020
1
2
3

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
