BMW R 1150 RT Repair Manual

33.8
•
Position rear wheel drive upright with retaining
fixture, BMW No. 33 1 510.
e Attention:
To prevent the input bevel pinion from being dam-
aged when it falls out, use a soft underlay.
•
Heat the housing until the input bevel pinion is
released (max. 120 °C/248 °C) and drops out.
•
Remove the input bevel pinion and the spacer.
33 12
Disassembling input bevel pinion
•
Remove outer bearing race (1).
•
Clamp input bevel pinion (2) into vise with protec-
tive jaws (splines facing upwards).
•
Using puller, BMW No. 00 7 500, pull off both
bearings at the same time.
•
Remove thrust ring (3).
•
Remove ball thrust bearing (4), inner race (5), roll-
er bearing cage (6) and outer race (7).
R21330010
w
h
120
33 1 510
R21330090
5
7
6
4
1
2
3
KR330100
00 7 500

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
