BMW R 1150 RT Repair Manual

00.6
Model R 1150 RT
Connection
21 Clutch
Clutch housing
Initial torque Nm 40
(oil screw threads lightly)
+ Additional wrench angle °
32
Housing cover to housing Nm 12
Clutch line to handlebar fitting Nm 14
Slave cylinder to gearbox Nm 9
Grub screw in filler adapter Nm 10
Model R 1150 RT
Connection
23 Transmission
Oil drain plug Nm 30
Oil filler plug Nm 30
Gearbox to engine block Nm 22
Shift lever to footrest plate Nm 35
Selector lever to selector shaft Nm 9
Housing cover to housing Nm 9
Frame tube to gearbox
1. to gearbox and left footrest plate Nm 42
(clean thread + Loctite 2701)
2. terminal block, frame tube to
gearbox
Nm 9
3. to gearbox and right footrest plate Nm 42
(clean thread + Loctite 2701)

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
