34.27
Filling and bleeding rear wheel circuit
e Attention:
Integral brakes, the front brake must be ready for
use.
– Place the motorcycle on its centre stand.
•
Open rear wheel-circuit reservoir (1).
•
Remove rear brake pads.
•
Install adapter, BMWNo.341536, instead of
the outboard brake pad.
•
Install resetting tool, BMWNo.341531, with
the handle toward the outside in the rear brake
caliper, press the pistons fully back and secure
them in this position.
e Attention:
To prevent brake fluid entering plugs, do not discon-
nect plugs from the ABS pressure modulator.
•
Screw container, BMW No. 34 1 581,
onto rear wheel circuit reservoir.
•
Slowly fill container, BMW No. 34 1 581, with
new brake fluid until it is approximately 1/3 full.
•
Connect the brake bleeding device to the bleed
screw, but do not switch on the device.
L Note:
If necessary, use a cable tie to secure the bleed
hose to the bleed screw.
•
Switch on the ignition
L Note:
After switching on the ignition, always wait for the
BMW Integral ABS to complete its self-diagnosis.
Do not operate the brake lever until self-diagnosis
has completed.
R28340110
1
R28000170
34 1 536
34 1 531
R22000350
34 1 581
