BMW R 1150 RT Repair Manual

23.12
23 00 043 Disassembling gearbox
23 11 Removing gearbox housing
•
Remove oil filler/level check screw (1).
•
Remove oil drain plug (2) and drain the oil from
the gearbox into a suitable tray.
•
Remove selector lever (3).
•
Carefully drive back centering pins (4), from the
cover side or casing side, as applicable.
•
Remove screws (5) securing cover to housing.
•
Set the gearbox down on its cover.
e Attention:
Avoid damage to the housing cover and painted sur-
faces.
•
Heat the bearing points in the housing
to 80 °C...100 °C (176 °F...212 °F).
•
Tap lightly with a plastic-faced hammer to disen-
gage the housing.
R21230020
3
5
2
1
4
4
R21230030
h
80 …100
w

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
