BMW R 1150 RT Repair Manual

11.22
Locking the engine at TDC
•
Remove front cover.
•
Turn the belt pulley to bring the piston to
firing TDC.
Firing TDC
1. TDC mark is visible, and
2. the cylinder’s inlet and exhaust valves are both
closed.
•
Install locking device, BMWNo.115640, to
lock clutch housing.
L Note:
The engine can be set to top dead centre with the
TDC pin,
BMW No. 11 2 650, which is inserted into the clutch
housing and the engine block at TDC.
R21110010
11 5 640
RS110461
11 2 650
TD

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
