Brother MFC-J2310 Service Manual

Confidential
2-89
4.10 Other Problems
4.10.1 The machine cannot be powered on
User Check
- Insert the AC cord securely.
4.10.2 Memory card/PictBridge does not function (no response)
User Check
- Check if the memory card is inserted correctly.
- Replace the USB cable.
- Check that memory card is compatible.
- Check that data form is compatible.
- Format the memory card.
- Load the latest firmware.
- Disconnect and insert again the AC cord.
4.10.3 Data of memory card/PictBridge does not read
User Check
- Check that memory card is compatible.
- Check that data form is compatible.
- Format the memory card.
- Load the latest firmware.
Step Cause Solution
1 Panel PCB harness connection
failure
Reconnect the panel PCB harness.
2 LCD defective Replace the control panel ASSY.
3 Condenser on the Main PCB
defective
Replace the condenser on the main PCB.
*For instructions on how to judge condenser
defective and how to replace condenser, refer to
APPENDIX 4. "REPLACEMENT OF
CONDENSER ON THE MAIN PCB."
4 Power supply PCB defective Replace the power supply PCB ASSY.
5 Main PCB defective Replace the main PCB ASSY.
Step Cause Solution
1 Inner media cover not mounted in
place
Set the inner media cover into place in the case the
memory card won't be inserted smoothly.
2 Main PCB defective Replace the main PCB ASSY.
Step Cause Solution
1 Main PCB defective Replace the main PCB ASSY.
