3-45
Confidential
9.3.9 ADF Hinge L
(1) Release the wiring of the ADF motor harness and the document detection/document
scanning position sensor harness.
Duplex scanning models: Release the wiring of the second side CIS flat cable.
ADF motor harness
Document detection/
document scanning
position sensor harness
ADF sensor harness
(3_021_1_E)
